Facility Mode의 Bypass Tunnel Facility Mode의 Bypass Tunnel Facility Mode는 여러 LSP를 동일한 Bypass Tunnel로 Protection할 수 있도록 함 - 이를 위해 PLR은 Bypass Tunnel을 요청하는 LSP의 RRO를 확인함 Detour Tunnel(Bypass Tunnel) - "bypass-node x.x.x.x" 또는 "bypass-link x.x.x.x"로 Bypass Tunnel의 유무를 결정함 - 이미 Bypass Tunnel이 있는 경우 · LSP가 동일한 Bypass Tunnel에 연결됨 - 아직 Bypass Tunnel이 없는 경우 · New Bypass Tunnel이 설정됨 RRO를 점검하는 방법 - PLR은 RRO를 확인하고 목록의 다음 노드를 결정함 - PLR은 Bypass Tunnel이 이미 설정되었는지 확인함 → Bypass Tunnel이 이미 존재한다면 기존 Byspass Tun...
![[MPLS Resiliency] Bypass Tunnel 동작 과정 - Signaling](https://mblogthumb-phinf.pstatic.net/MjAyMjA3MjhfMjYz/MDAxNjU4OTY2MTY1OTEz.KUB3Y2En3I8u-z4yBUcx5riPbJQnkWz-rkfSa8ayZfQg.eqE8bGup4qoR3MJKfx8hmP3Tnl5g1__jwJDrEWRjASwg.PNG.choiyoonjun111/image.png?type=w2)
#
