Floating Static Routing Case Study (Cisco) 작업 개요 목적 Floating Static Routing을 설정하여 Main Route가 Down될 시 Routing Table이 어떻게 변경되는지 확인한다. 일자 2022.08.10(수) 테스트 내용 1.
Floating Static Routing Case Study - 구성도 2. Cisco 기본 설정 3.
Interface 설정 4. OSPF 설정 5.
Floating Static Routing 설정 6. Main Route Down 후 Routing Table 확인 7.
Main Route Up 후 Routing Table 확인 테스트 계측기 - 장비 / OS L3 Cisco / IOS c3725-adventerprisek9-mz.124-15.t14 결과 1. AD=10, AD=20인 Static Routing을 구성했을 때 AD가 낮은 Route만 Routing Table에 올라옴 - AD가 높은...
