IGMPv3 동작 과정 - General Query / Report IGMPv3 동작 과정 - General Query / Report 1. 이미 Client는 처음 Report를 발송하여 라우터에 위 그림과 같은 Membership Table이 생성된 상태임 2.
라우터가 General Query를 224.1.1.1로 전송하여 모든 Client가 수신함 3. 모든 Client가 받고자 하는 정보가 다르므로 각각 Report를 전송함 - 처음에는 Report의 Type을 "new"로 전송했지만 지금은 이미 전달한 정보이므로 1.1.1.1에 대한 정보만 "Include" 시켜 달라고 Type을 "Include"로 전송함 - General Query를 발생시키면 모든 Client가 Report 메시지를 전송함 4.
라우터가 모든 Report를 수신하면 Membership Table을 계속 유지할 수 있음 IGMPv3 동작 과정 - Specific Query IGMPv3 동작 과정 - S...
