Link Aggregation LACP ② Case Study(Nokia 7705 SAR) 작업 개요 목적 LACP(Active ↔ Passive)를 사용할 때 Link Aggregation의 동작을 확인한다. 일자 2022.12.29(목) 테스트 내용 01.
Link Aggregation LACP Case Study - 구성도 02. LACP 설정 03.
LACP 설정 확인 테스트 계측기 - 장비 / OS L3 Nokia / 실장비 TiMOS-B-8.0.R10 결과 각 라우터에 Active Mode와 Passive Mode를 사용하면 Link Aggregation이 정상 동작함 01. Link Aggregation LACP Case Study - 구성도 02.
LACP 설정 R1 configure port 1/2/1 description LACP-Interface // 포트의 Description을 지정 ethernet mode network // 해당 포트의 Ethernet M...
