RIP Split Horizon Case Study(Cisco) 작업 개요 목적 RIP의 Split Horizon을 설정하고 동작을 확인한다. 일자 2023.01.03(화) 테스트 내용 01.
RIP Split Horizon Case Study - 구성도 02. 기본 인터페이스 설정 03.
기본 인터페이스 설정 확인 04. RIPv2 설정 05.
RIPv2 Split Horizon 설정 06. RIPv2 Split Horizon 동작 확인 테스트 계측기 - 장비 / OS L2 Cisco / IOL I86BI_LINUXL2-ADVENTERPRISEK9-M / Version 15.1 L3 Cisco / IOS C3725-ADVENTERPRISEK9-M / Version 12.4(15)T14 결과 Split Horizon을 설정하면 라우팅 정보를 수신한 인터페이스로 같은 라우팅 정보를 업데이트하지 않음 - DB에서 각 네트워크마다 Best-Path라고 인식하는 인터페이스로 업데이트하지 ...
![[RIP] RIP Case Study - Split Horizon(Cisco)](https://mblogthumb-phinf.pstatic.net/MjAyMzAxMDNfMTM5/MDAxNjcyNzA0MTk0NTU3.nDcv_c1ngCE03JyDsJNlUYoiOXZQkBaP1wg5_Qfvnxsg.bGbQkilHlo1qfi7cklIH2vMcVXp-PS39ALwcVCRc0Skg.PNG.choiyoonjun111/image.png?type=w2)
#
