HSRP Preempt Case Study(Cisco) 작업 개요 목적 HSRP를 설정하고 Preempt 옵션 동작을 확인한다. 일자 2022.12.31(토) 테스트 내용 01.
HSRP Preempt Case Study - 구성도 02. 기본 인터페이스 설정 03.
기본 인터페이스 설정 확인 04. OSPF 설정 05.
OSPF 설정 확인 06. HSRP 설정 07.
HSRP 설정 확인 08. Preempt 옵션 미적용 후 HSRP Active 재부팅 09.
Preempt 옵션 적용 후 HSRP Active 재부팅 테스트 계측기 - 장비 / OS L2 Cisco / IOL I86BI_LINUXL2-ADVENTERPRISEK9-M / Version 15.1 L3 Cisco / IOS C3725-ADVENTERPRISEK9-M / Version 12.4(15)T14 결과 Priority 값이 동일해도 IP가 높은 장비를 Active로 선출하지 않음 - 먼저 Active로 선출된 장비...
