HSRP Owner Case Study(Cisco) 작업 개요 목적 VRRP를 설정하고 Owner 옵션 동작을 확인한다. 일자 2022.12.31(토) 테스트 내용 01.
HSRP Owner Case Study - 구성도 02. 기본 인터페이스 설정 03.
기본 인터페이스 설정 확인 04. OSPF 설정 05.
OSPF 설정 확인 06. HSRP 및 Owner 설정 테스트 계측기 - 장비 / OS L2 Cisco / IOL I86BI_LINUXL2-ADVENTERPRISEK9-M / Version 15.1 L3 Cisco / IOS C3725-ADVENTERPRISEK9-M / Version 12.4(15)T14 결과 Priority 값이 동일할 경우 IP가 높은 장비를 Master로 선출함 - 먼저 Active로 선출된 장비가 Active 상태를 유지함 HSRP는 Owner를 지원하지 않음 01.
HSRP Owner Case Study - 구성도 02. 기본 인터페이스 설정 R...
