Dynamic NAT - Load Balancing Case Study(Cisco) 작업 개요 목적 Dynamic NAT에서 Load Balancing이 되도록 설정하고 동작을 확인한다. 일자 2023.01.30(월) 테스트 내용 01.
Dynamic NAT Case Study - 구성도 02. 기본 인터페이스 설정 03.
기본 인터페이스 설정 확인 04. OSPF 설정 05.
OSPF 설정 확인 06. Default-Route 설정 07.
Default-Route 설정 확인 08. Telnet 설정 09.
Dynamic NAT - Load Balancing 설정 10. Dynamic NAT - Load Balancing 동작 확인 테스트 계측기 - 장비 / OS L3 Cisco / IOS / 7206VXR C7200-ADVIPSERVICESK9-M / Version 15.2(4)S5 결과 Dynamic NAT를 이용하여 Load Balancing을 이용할 수 있음 외부→내부로 ...
