LANGER HR-E 40-1set E-Field Probe up to 40 GHz, RF Probe

HR-E 40-1 set E-Field Probe up to 40 GHz Short Description The HR-E 40-1 is a passive near-field probe for measuring electric fields up to 40 GHz. The probe is placed vertically and centrally on the RF trace for measurement.

By placing the probe directly on the RF trace, a defined distance (0.5 mm) between RF trace and measuring electrode is achieved. The measuring tip is decoupled from the cable shield by special damping systems.

In addition, the probe contains a current attenuator. The probe i...
