미국 InertialLabs_이너셜랩 사에서 FOG(Fiber Optic Gyroscopes) 자이로를 내장한 IMU가 새롭게 출시되었습니다. 1. 제품명 : IMU-FI-200C 2.
구성 3축 전술급, Closed-loop FOG 자이로 3축 전술급, MEMS 가속도계(Accelerometers) 3. 스펙 Gyro bias repeatability : 0.5 deg/hr (over temp. range) Gyro noise (ARW) : 0.025 deg/root hr (typical) Accel bias in-run stability : 0.015 mg (RMS) Accel bias repeatability : 1.2 mg (over temp. range) Accel SF accuracy : 300 ppm (over temp. range) 4.
Electrical 소모전력 : 5.5 Watts @ 5V 인터페이스 : UART(RS-422) 혹은 SDLC(synchronous ...
![[소식] 미국 InertialLabs사, 신규 FOG IMU 출시](https://mblogthumb-phinf.pstatic.net/MjAyMjExMjNfMTQz/MDAxNjY5MTY1Mzg1NjM0.eP5bTj1MlSLgfX8WCu7qGG0t8PFhPw0NntXwe_vA-xYg.90RPhtZkx7wNpE_h_vnB2jdhO4H9CGDYNJxlQzzjbCMg.PNG.pinpointsolutions/42.png?type=w2)
#
